Features
FOREFRONT™ SUSPENSION SYSTEM
The system utilizes four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.
ENGINE
- Powered by Vanguard™ 810cc EFI air cooled petrol engine.
- Automotive-based, closed-loop Electronic Fuel Injection system.
- More favorable gasoline consumption over carbureted equivalent.
- Rugged twin 21 litre fuel tanks (42 litres total).
- Dual-stage industrial air-cleaner extends engine service life.
- Vanguard Oil Guard System – Extending oil exchange interval to 500 hours.
OPERATOR CONTROL & COMFORT SYSTEMS
- Ergonomic control panels feature a cup holder, storage compartment and fuel gauges for operator convenience.
- Folding Roll Over Protection Structure (ROPS) with retractable seat belt.
- Flip-up seat for easy service access.
- Premium mid-back seat with armrests and adjustable fore and aft positioning.
- Removable floor plate for easy maintenance access.
MOWER DECK
- Available in 155 cm cutting width
- TRIPLE mowing technology: All-in-One mower deck comes with side discharge, rear discharge and mulching capabilities out of the box.
- Foot-operated deck lift, with adjustable pedal, can change cut height in 6 mm increments from 3.8 – 12,7 cm.
- Features top greaseable cast-iron spindles.
- 2-belt deck drive system improves belt life and is more dependable.
CHASSIS
- Dual, commercial Hydro-Gear® ZT-4400™ transaxles feature 21 cm cooling fans that also assist with repelling debris.
- Heavy-duty integrated rear bumper protects engine compartment.
